Leeboy L600

LEEBOY L600 — TACK DISTRIBUTOR

Perfect for the all-inclusive commercial paving contractor, the L600 Tack Distributor provides a large-sized tank for projects including parking lots, patching, driveways or soil stabilization. Daily tasks can be completed with ease by relying on the trouble-free Gas-powered engine and the proven reliable user-friendly design. Uniquely configurable, the customizable options give the contractor the ability to create a solution specific to their exact needs.

PERFORMANCE FEATURES

• 600 Gallon (2,271 l) Capacity Tank

• 4.8 hp (3.6 kw) Honda Engine

• 6’ (1.8 m) Wand with On/Off Valve

• 40’ (12.19 m) Heavy-Duty Recoil Hose Reel

• 7,275 lbs (3,299 kg) Loaded Weight

• 1” (25 mm) Rear Tank Sampling Valve

• One 300,000 BTU Propane Burner

• Trailer-Mounted or Skid-Mounted Configurations

• Electric brakes

• Emergency Brake-Away System

• Optional Accessories Available

TRAILER SPECIFICATIONS (FOR TRAILER CONFIGURATION)

• 6,000 lb axles with a pintle eye

• 5,000 lb jackleg

• Wired for towing

• Tires: ST 225/75D15

• Electric brakes on axles

• Safety chains

• Emergency breakaway switch with battery backup

ENGINE

• 4.8 HP (3.6 kw) Honda

• 1 gallon fuel tank

HEAT SYSTEM

• One 300,000 BTU propane burner

• One starter burner

• 40 lbs (18.1 kg) propane fuel tank

ASPHALT PUMP

Specially designed 7 gallons per minute (26.5 lmp) pump

TEMPERATURE GAUGE

• 50 - 300⁰ F (10 - 149⁰ C)

• Adjustable angle face plate

FLUSH TANK

7 gallons (26.5 l) tank with suck back valve

WAND

• 6’ (1.829 m) wand with cold handles

• On/off valve

• Removable spray tip

HOSE AND REEL

.5” x 40’ (13 mm x 12.192 m) heavy-duty recoil hose reel

MANHOLE

• 20" (508 mm) diameter

• 10" (254 mm) diameter fill hose

• 3 psi (2.1 bar) pressure relief

CLEAN OUT

4” (102 mm)

SAMPLING VALVE

1” (25 mm)

ADDITIONAL STANDARD EQUIPMENT

• Waste bucket mount (trailer only)

• 1” rear tank return

• 2” in-tank overflow

OPTIONAL EQUIPMENT

ENGINES

• Honda gas - 4.8 hp (3.6 kW) electric start

• Hatz diesel - 7.2 hp (5.4 kW) pull start or electric start

• Fuel: 1.32 gallons (5.0 l)

HEAT SYSTEMS

• Diesel Burner - One 300,000 BTU diesel burner (only available with electric start engines), 7 gallon (26.5 l) fuel tank, Auto ignition diesel burner with outfire

• Overnight Heat - 120 volt/1500 watt, Immersion element

SPRAY BAR

• Spray width: 12’ (3.65 m)

• Spray Bar Controls: In-truck wireless remote controls (requires spray bar option)

• Spray bar lift with wireless remote control

Insulated Tank

Specifications are subject to change without prior notice.

Similar models may be shown in addition to the featured model. Equipment may be shown with options.
